Operating conditions
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
50
of 328
3.3
3.3.5.2 Correction values for the output current of the axis units BM53XX
Operating temperature T
U
k
T
Correction value operating temperature
Air-cooled
Water-cooled/Cold plate
Figure 19: Correction value k
T
in dependence of the temperature T
U
, BM53XX
Installation altitude H
k
H
Correction value installation altitude
Figure 20: Correction value k
H
in dependence on the installation altitude H, BM53XX
