Monitoring
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
212
of 328
8.3
8.3 Monitoring
8.3.1 Monitoring BM50XX
The controller unit monitors the device during operation. If the controller unit detects a
state that deviates from the normal operation condition, the device generates an error
message.
Error message If the controller unit detects that the device is not working error-free, then this is shown
via the LEDs
H1 to H4 (see ZDisplay and operating elements– as from page 90 for de-
vices without safety function and see ZC.4 LED display BM5030 with safety function– as
from page 306 for devices with safety function).
For further information see ZTroubleshooting and Fault correction– as from page 227.
8.3.2 Monitoring BM51XX, BM53XX
The controller unit monitors the device during operation. If the controller unit detects a
state that deviates from the normal operation condition, the device either generates a
warning or an error message.
Warning If the controller unit detects an operating condition that exceeds a warning threshold, a
corresponding warning is shown on the display or, respectively, controller. The most im
-
portant warning message (Current limit reached) is also shown by the device through the
LED
H13 or H23 (see ZDisplay and operating elements– as from page 90).
Error message If the controller unit detects that the device is not working error-free, then this is shown
via the LED
H14 or H24 (see ZDisplay and operating elements– as from page 90). A cor-
responding error code will continue to be shown on the display and/or a controller can
read out the error code on the device.
For further information see ZTroubleshooting and Fault correction– as from page 227.
