Baumuller b maXX 5000 - Special DC Link Connection BM519 X, BM537 X

Preparing for mounting
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
118
of 346
6.2
For all
versions:
*: Relative tolerance of discretionary divisions: ±0.1 mm
Figure 48: Drilling pattern without mounting rail for all versions
Cutout for
BM537X-F:
Figure 49: Cutout BM537X-F
351.9
158
11.8
11.8
16.5
25
16.5
25
