Installation
Instruction handbook bmaXX 5000
Document No.: 5.09021.19
137
of 346
7
m Grounding concept, PE-connection from device to device, cooling type S
Power supply PE bar
Figure 62: Grounding concept, PE connection from device to device
1 (Active) mains rectifier unit
2 Single axis unit 75 mm
3 Single axis unit 50 mm
4 Double axis unit 50 mm
5 Double axis unit 75 mm
6 Mounting plate, thickness at least 3 mm
NOTE!
The first and last device must be connected directly with PE if the PE connection is
realized from device to device. An accessories kit is available for the connection from
device to device, see ZAccessories kit PE connection from device to device– on
page 304, part No. 467439.
