1C1, 1D1 Connections for the DC link, see ZFigure 77– on page 160.
X2 Connections for pulse enable, etc. see ZX2 D
igital inputs/outputs– on page 177
X7 Encoder evaluation
X107 Motor connection BM5326, BM5327, BM5328, see ZFigu
re 77– on page 160
1U2, 1V2, 1W2 Connections for the motor BM5334, BM5335, see ZFigu
re 78– on page 161.
Connections for the motor BM537X, see ZFi
gure 79– on page 162
X200 Connections for 24 V voltage supply; for additional information, see ZFigu
re 77– on page
160 (SELV/PELV).
X206 Connection for 24 V voltage supply for the motor brake, see Table X206 on Zpag
e 168–.
For connector assignment see ZX2
06/X207/X208– as from page 198.
X207 Connections for motor temperature and motor brake of motor 1,
see table X207 on Zpag
e 169–.
For connector assignment see ZX2
06/X207/X208– as from page 198.
X208 Connections for motor temperature and motor brake of motor 2,
see table X208 on Zpag
e 169–.
For connector assignment see ZX2
06/X207/X208– as from page 198.
X300 Signal bus
