Analog inputs
Linearity error inputs in LSB
Voltage input Current input
Resolution 14 bit
Type Differential input
Input resistance Approx. 50 k Approx. 100 
Input current Max. 250 µA Min. (0)
 4A,
Max. 20 mA
Input voltage -10 V to +10 V Max. 2 V
Sampling rate 125 µs
Power supply encoder Max. 250 mA per connection
Error Min Type Max
DNL 0 2 4
INL 0 3 6
Offset 0 3 6
Gain 0 3 6
NOTE!
The connections of the cables of the analog channels must be done shielded.
Blade terminals with 6.3 mm width are available for connecting the shields.
