BM5030 with Safety Function
Instruction handbook b maXX 5000
Document No.: 5.09021.16
305
of 328
B
1)
All rated values are based on an power supply voltage of 400 V/50 Hz, a DC link voltage of 540 V, a control
voltage of 24
V and a surrounding temperature of 40 °C.
2)
The input current must be reduced between 40 °C and 55 °C, see correction values at changed operation
conditions, see
ZCorrection values for the output current of the mains inverter BM50XX, BM51XX– on page
49.
3)
The mains rectifier draws the rated/peak current at rated supply voltage. The input current must be reduced
if power supply voltage is higher than 400 V and the DC link output power remains constant, see
ZDerating:
Input current BM503X, BM504X, BM517X, BM519X– on page 52.
4)
The actual possible overload time depends on the preloading of the device and the heat sink temperature
and is detected by the overload monitoring of the device.
5)
With the permissible continuous DC link connected power, the power supply current is reduced. When se-
lecting the connected axes ensure that the DC link connected power is not exceeded, see ZDerating: DC link
power B503X, BM504X, BM517X, BM519X– on page 55.
6)
This power consumption is only permitted for a short period of time. This must be ensured by means of ap-
propriate configuration of the connected axes.
7)
Without loads on the digital outputs
8)
Residual voltage < 60 V
DC
9)
It is allowed to connect an additional capacitance to connector X101.
The total capacitance connected to the DC link (upstream of the STO function) is limited to 3.15 mF.
10)
Maximum DC link capacitance connected downstream the STO function.
