Technical data
Instruction handbook b maXX 5000
Document No.: 5.09021.16
65
of 328
3
1)
All rated values are based on an power supply voltage of 400 V/50 Hz, a DC link voltage of 540 V (BM50XX)
or 640 V (BM51XX), a control voltage of 24 V and a surrounding temperature of 40 °C.
2)
The input current must be reduced between 40 °C and 55 °C, refer to correction values at changed operation
conditions, ZCor
rection values for the output current of the mains inverter BM50XX, BM51XX– on page 49.
3)
The mains rectifier draws the rated/peak current at rated supply voltage. The input current must be reduced
if power supply voltage is higher than 400 V and the DC link output power remains constant, refer to ZDer-
ating: Input current BM503X, BM504X, BM517X, BM519X– on pa
ge 52.
4)
The actual possible overload time depends on the preloading of the device and the heat sink temperature
and is detected by the overload monitoring of the device.
5)
With the permissible continuous DC link connected power, the power supply current is reduced. When se-
lecting the connected axes ensure that the DC link conne
cted power is not exceeded, refer to ZDerating: DC
link power B503X, BM504X, BM517X, BM519X– on page 55.
6)
This power consumption is only permitted for a short period of time. This must be ensured by means of ap-
propriate configuration of the connected axes.
7)
Including external power choke
8)
Without loads on the digital outputs
9)
Residual voltage < 60 V
DC
10)
It is necessary to connect a quick discharge resistor or a brake resistor!
11)
Cold plate version max. 30 s
For details refer to ZLoad cycle
according EN61800-6– as from page 75
12)
For further information refer to parameter 141.8 DC link voltage set value at parameter manual b maXX 5000
13)
Between the min. waiting time (internal DC link capacitance only) and the max. waiting time (maximum DC
link capacitance) can be linearly interpolated depending on the total capacitance value.
14)
Mains inductance u
k min
= 0,5 %
NOTE!
The distortion factor of the input cur
rent of following devices
BM50XX-XR /XS /XW ,, is at least twice as m
uch the factor at operation with power choke.
The user has to check with the local power supplier whether
an operation without power choke is allowed.
