Electrical data
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
80
of 346
3.4
3.4.4.2 Load cycle BM51XX, BM53XX
Operation with constant load
Figure 36: Typical current-time diagram: operation with constant load
BM51XX
BM53XX
I
b
BM5174 S (air-cooled)
BM5174 C (cold plate)
100 A (100 % I
rated
)
BM5192 216 A (100 % I
rated
)
BM5193 290 A (100 % I
rated
)
I
b
at 2 kHz I
b
at 4 kHz I
b
at 8 kHz I
b
at 16 kHz
BM5323 - 2 x 3 A (100 % I
rated
)2x2.1A (70%I
rated
)-
BM5325 - 2 x 6 A (100 % I
rated
)2x4.2A (70%I
rated
)-
BM5326 - 12 A (100 % I
rated
) 8.4A (70%I
rated
) 4.8A (40%I
rated
)
BM5327 - 20 A (100 % I
rated
) 14A (70%I
rated
) 8A (40%I
rated
)
BM5328 - 30 A (100 % I
rated
) 21A (70%I
rated
) 12A (40%I
rated
)
BM5331 - 2 x 12 A (100 % I
rated
) 2x8.4A (70%I
rated
)2x4.8AA (40%I
rated
)
BM5332 - 2 x 20 A (100 % I
rated
) 2x14A (70%I
rated
) 2x8A (40%I
rated
)
BM5333 - 2 x 30 A (100 % I
rated
) 2x21A (70%I
rated
) 2x12A (40%I
rated
)
BM5334 - 40 A (100 % I
rated
) 28A (70%I
rated
) 16A (40%I
rated
)
BM5335 - 60 A (100 % I
rated
) 42A (70%I
rated
) 24A (40%I
rated
)
BM5372-S 120 A (100 % I
rated
) 90A (75%I
rated
) 63A (52%I
rated
) 45A (37%I
rated
)
BM5372-F
BM5373-S 150 A (100 % I
rated
) 120 A (80 % I
rated
) 84A (56%I
rated
) 50A (33%I
rated
)
BM5373-F 60 A (40 % I
rated
)
BM5374-S 180 A (100 % I
rated
) 150 A (83 % I
rated
) 105 A (58 % I
rated
) 50A (27%I
rated
)
BM5374-F 100 A (55 % I
rated
) 75A (41%I
rated
)
BM5375-F 180 A (100 % I
rated
) 180 A (100 % I
rated
) 130 A (70 % I
rated
) 90A (50%I
rated
)
BM5376-S 180 A (100 % I
rated
) 150 A (83 % I
rated
) 105 A (58 % I
rated
) 50A (27%I
rated
)
BM5376-F 180 A (100 % I
rated
) 130 A (72 % I
rated
) 90A (50%I
rated
)
