4 Repair, Maintenance and Service Volume 2
Figure 4-6 Digital board
Digital board versions There are three versions of digital boards. The current version is
described in detail in this User's Manual and is called digital board
3.
The digital boards can be exchanged against each other; depending
on the digital board, a different software may have to be installed
(see the following table).
7
98
Dismantled digital board
9
Uni-Probe serial
number
Digital board
version
ID no. Software
revision
Revision of embedded
software
up to 6xxx 1 35966 <100 1.xx
7000 and higher 2 48631 100 to <200 2.xx
8000 and higher 3 52256 200 and higher 3.xx
