Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
3 – 299
Volume 3 2 Menu Structure
3
2 Menu Structure
2.1 Information on the Menu Structure
The menu structure on the next 2 pages provides an overview over
all functions of the Uni-Probe. Using the page numbers indicated
you can look up the function of the depicted window. The windows
are depicted as they appear on the Communicator.
The menu is divided into:
• Reading values
All values in the menus
LIVE DISPLAY and VIEW PARAMETERS
are reading values which are accessible to each user without
password. In the menu structure this area is indicated as read
only.
• Parameters
Select the menu item
SETUP to go to the editable parameters.
Access to these parameters can be protected via a password. In
the menu structure this range is indicated as read and write.
First ENTER then SEND To rule out incorrect entries, you always have to push the SEND
softkey immediately after you have entered a value via the
ENTER
button. The
SEND softkey is only visible after values have been
changed.
–Push
ENTER to save edited values and parameters in the
Communicator.
–Push
SEND to transfer all modified values from the commu-
nicator to the Uni-Probe.
The following sections require that you:
• know how to operate the Communicator
• have read and understood Volume 2 ("Uni-Probe Installation")
of this User’s Manual.
