BERTHOLD TECHNOLOGIES Uni-Probe LB 490 - 1 PC Connection to the Uni-Probe; Connection with active current output; Connection with passive current output

Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
4 – 407
Volume 4 1 PC Connection to the Uni-Probe
4
1 PC Connection to the
Uni-Probe
Practical examples for PC connection:
1. Connection with active current output
2. Connection with passive current output
3. Connection with passive current output and instrumentation
1.
2.
3.
