Volume 3 5 Functional Processes
3
5 Functional Processes
The following chapter describes the major functional process that
occur when working with the Uni-Probe.
5.1 Plateau Measurement
If the following display does not come up, then select it, starting
from the Start menu, via the following path:
ACCESS TO SETUP  FULL ACCESS  SERVICE  PLATEAU.
 Select
PLATEAU MEASURE.
 Select YES.
If you want to continue with the standard setting, then you have to
select
NO. Skip the next 4 windows and continue with START PLA-
TEAU MEASUREMENT NOW?
 Enter the high voltage where the plateau measurement should
start and confirm the input with
ENTER.
 Enter the high voltage where the plateau measurement should
end and confirm the input with ENTER.
