BERTHOLD TECHNOLOGIES Uni-Probe LB 490 - 3.2 VIEW Menu; 3.2.1 DISPLAY

38477BA2B
6 – 592 25.5.09
3 Device-specific Menus Volume 6
3.2 VIEW Menu
The VIEW menu includes setting options for program view and live
display of the measured values.
The VIEW menu includes the following items:
• Display (page 6–592)
• Y t diagram (page 6–595)
• Alarm States (page 6–597)
– Function Block 1 - Analog Input (page 6–597)
– Function Block 2 - Analog Input (page 6–599)
• Device Status (page 6–599)
• Toolbar (page 6–599)
• Status Bar (page 6–599)
• Update (page 6–599)
Description of the Menu Items
3.2.1 DISPLAY
The VIEW menu includes 4 submenus which can be selected on the
tab…
• Function Block 1 - Analog Input (page 6–592)
• Function Block 2 - Analog Input (page 6–593)
• Measured Value (page 6–593)
• Probe Raw Data (page 6–594).
FUNCTION BLOCK 1 - ANALOG INPUT
Tab
The FUNCTION BLOCK 1 - ANALOG INPUT dialog box shows the cur-
rent output value of function block 1.
