38477BA2B
7 – 696 25.5.09
5 Functional Processes Volume 7
5.5 Radiation Interference Detection
Go to the function block RESOURCE.
In the record LE_INTERFERENCE_DETECTION enable or disable
the radiation interference detection via the parameter
LE_DETECTION_MODE.
Send the entry to the Uni-Probe.
In the parameter
LE_DETECTION_THRESHOLD, enter the
threshold value for the start of the suppression of sensor val-
ues.
In the parameter
LE_DETECTION_HOLD_TIME, enter the dura-
tion of the suppression, i.e. the time the measured pulse rate is
not taken into account.
Send the entries to the Uni-Probe.
This completes the setting.
5.6 Input Configuration
Two digital inputs are available.
Go to the function block
RESOURCE.
With the parameter
LE_DIGITAL_INPUT_ENTRY, select the
input you want to set up: Dig. Input Hold or Dig. Input Empty.
Send the entry to the Uni-Probe.
Enable or disable the respective input via the parameter
LE_DIGITAL_INPUT_FUNCTION.
Send the entry to the Uni-Probe.
This completes the setting.
The status of the digital inputs can be viewed in the record
LE_DIGITAL_INPUT_TEST_VALUES.
Parameters used
LE_INTERFERENCE_DETECTION
LE_DETECTION_MODE
LE_DETECTION_THRESHOLD
LE_DETECTION_HOLD_TIME
Parameters used
LE_DIGITAL_INPUT_ENTRY
LE_DIGITAL_INPUT_FUNCTION
