5.9 Protecting Parameters against Modifi-
cation
Parameters can be protected against modification to rule out that
parameters in the Uni-Probe will be changed inadvertently.
 Go to the function block RESOURCE.
 Set the value for WRITE_LOCK to Locked.
 Send the entry to the Uni-Probe.
This completes the setting.
5.10 Reading Out the Error Log
 Go to the function block RESOURCE.
•The value of ERROR_LOG_NUMBER corresponds to the total
number of errors in the log.
 Set the value for ERROR_LOG_ENTRY to the error number for
which you would like to view information.
 Send the entry to the Uni-Probe.
The record
ERROR_LOG_DATA includes the information you are
looking for.
Parameters used
WRITE_LOCK
Parameters used
ERROR_LOG_DATA
ERROR_LOG_ENTRY
ERROR_LOG_NUMBER
