Volume 3 3 Getting Started via the HART
®
Communicator
3
3 Getting Started via the
HART
®
Communicator
Before taking the device into operation, make sure that
– the device is not damaged
– the device has been installed according to instructions
– the connections have been established according to instructions
– the cables and lines have been inserted properly
– unused cable bushings have been sealed by dummy plugs
according to the directive 94/9/EG
– the cover is tightened firmly
– the dummy plugs and the screwed cable glands or the conduits
are firmly tightened.
The Level Gauge can be taken into operation either via the HART
®
Communicator or via a PC and the SIMATIC PDM software.
Basically, the procedure for getting started is nearly identical for
both versions. The difference is only in the interface through which
the Level Gauge communicates.
This chapter describes how to take the Level Gauge into operation
via the HART
®
Communicator.
3.1 Steps for Getting Started
Step Activity Page
1 Check if the Device Description is installed on the
HART
®
Communicator (see User's Manual (HART
®
Communicator); if necessary, have it installed by
the manufacturer.
–
2 Connect HART
®
Communicator 3–297
3Turn HART
®
Communicator on (see User's Manual
HART
®
Communicator)
–
4 Calibrate Level Gauge 3–341
5 Create setup protocol 3–338
