38477BA2B
2 – 282 25.5.09
6 Technical Drawings Volume 2
6.7 Rod Source Shielding
1 Point source
2 Radiation exit
3Padlock
4Position Open
5Position Closed
6Type plate
Type d
mm
approx.
Kg/m
A B C D E F
mm
G H J K
approx.
M P
mm
80 80 100 320 285 130 80 41 14 93 235 15 204.5 90 11.5
100 100 130 340 305 140 80 41 14 107 255 15 224.5 100 11.5
120 119 190 400 360 165 80 47 18 128 310 20 270 120 11.5
150 150 300 465 425 195 100 65 18 147 375 20 334 150 14
200 190 450 560 510 235 120 75 25 184 450 25 400 180 14
270 254 780 580 510 230 125 100 26 207 545 25 503
222.
5
14
