Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
6 – 595
Volume 6 3 Device-specific Menus
6
3.2.2 Y T DIAGRAM
Shows a trend view of the measurement values.
The
Y T DIAGRAM dialog box shows a trend view of the measured
values and includes 2 submenus that can be selected on the tabs
• Function Block Outputs (page 6–595)
• Transducer Block Outputs (page 6–596).
FUNCTION BLOCK OUTPUTS Tab Two trend curves are displayed over the time:
• Level
• Detector temperature
HV Mode Shows the live HV operation mode of the selected probe.
Manual: A fixed HV has been set on the Service menu. It will be used for
servicing only.
Auto: The detectors operate with automatically controlled HV. In this
operating mode, a temperature drift is compensated.
The standard setting Auto must be kept to retain the drift stability
of the detector. Changes can only be made on the Service menu
Temperature ~ Shows the current temperature inside the probe. The sensor is located on
the electronic board. The temperature can be indicated in Fahrenheit or in
Celsius. The corresponding unit is selected during device configuration.
Number of Probes ~ Shows the activated number of Main and Auxiliary Units, which can be
used in this measurement system. "3" means that the Main Unit has been
enabled for two Auxiliary Units.
Parameters Input Description
