3 Device-specific Menus Volume 6

The scaling range of the display and the properties of the display

but can be adapted (see SIMATIC PDM documentation).

TRANSDUCER BLOCK OUTPUTS Tab Four trend curves are displayed over the time:

• Level

•CPS

•HV Reading

•Temperature
