BERTHOLD TECHNOLOGIES Uni-Probe LB 490

To Next Page

To Previous Page

38477BA2B

2 – 252 25.5.09

6 Technical Drawings Volume 2

6.1.1 Point Detector Mounting Clamps

76 mm (without water cooling)

90 mm (with water cooling, plastic ring not needed)

Mounting clamps for ID no.

Point detector without water cooling 39246

Point detector with water cooling 39247
