BERTHOLD TECHNOLOGIES Uni-Probe LB 490

To Next Page

To Previous Page

38477BA2B

3 – 322 25.5.09

Menu Structure Volume 3

2.24 SAVE & LOAD CURVE

1 SAVE

Saves the existing calibration data set to a separate memory. This

data set can be restored any time with

LOAD.

2 LOAD

Loads the saved calibration data set and overwrites the existing

calibration. You are prompted to confirm this action.
