3.2.2 Calibration Values
 Fill out the following table after you have completed calibration.
Upper Range
Lower Range
Alarm Code
Error Value
Relay 2
Function
Limit
Hysteresis
Relay 3
Function
Limit
Hysteresis
Relay 4
Function
Limit
Hysteresis
Function Range SETUP
Number of calibration points
Background
Calibration
point no.
Level in % CPS
1
2
3
4
5
6
7
8
9
10
