38477BA2B
7 – 670 25.5.09
3 Parameter Overview Volume 7
LE_TAB_OP_CODE Selection field with the following functions:
– Write table: Writes the calibration values to the Uni-Probe
All temporarily stored calibration values are written to the Uni-Probe.
The calibration values become effective as calibration curve in the
Uni-Probe only with Write table.
– Read table: Reads the actual calibration values from the Uni-Probe
– Save table: Saves the calibration values to a separate memory
(EEPROM) for data backup
– Load table: Loads the calibration values that have been saved earlier
with Save table
– Sort and check TAB: Checks the validity of calibration values and sorts
the value pairs. An error message is output if the calibration values do
not supply any valid calibration curve.
See section 4.5 on page 7–684.
LE_TAB_STATUS Shows if the instruction Sort and check TAB in LE_TAB_OP_CODE has
been successful or not. See section 4.5 on page 7–684.
LE_TAB_X_Y_VALUE
LE_TAB_X_Y_VALUE
LE_TAB_X_Y_VALUE
Record with the calibration values when using multi-point calibration. See
section 4.5 on page 7–684.
Level value
Pulse rate value
LE_TEMPERATURE_UNIT Unit for the temperature values in LE_TEMPERATURE and
LE_DETECTOR_TEMPERATURE. You may choose °C or °F. The conversion
takes place automatically in the Uni-Probe.
LE_TEMPERATURE
VALUE
Status
Temperature value measured by the Uni-Probe.
Status information regarding the temperature value.
PRIMARY_VALUE_TYPE Type of measurement signal. The information is automatically set to Level
and must not be changed.
PRIMARY_VALUE
VALUE
Status
Process value in the unit defined with LE_PRIMARY_VALUE_UNIT. This
value is identical with VALUE of LE_LEVEL.
Status information regarding the process value.
ST_REV Revision level of the static data of the function block. Incremented by one
whenever the static data change.
XD_ERROR Error message in text form according to FF Transducer Specification Sec-
tion 4.7 (Block Alarm Subcodes)
Parameter name Description
