BERTHOLD TECHNOLOGIES Uni-Probe LB 490 - Page 7

Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
7
Volume 1-7 Contents
Volume 2 Uni-Probe Installation
1 System Description.......................................................... 2 – 119
1.1 Measuring System ..................................................2 – 119
1.2 Uni-Probe Hardware ............................................... 2 – 123
1.3 Measuring Principle ................................................ 2 – 125
1.4 Measuring Arrangements ....................................... 2 – 126
1.5 Technical Data ........................................................ 2 – 130
1.6 Detector Codes ...................................................... 2 – 133
1.7 Uni-Probe LB 490 Nomenclature ............................. 2 – 134
1.8 LB 490 Super-Sens Nomenclature ...........................2 – 135
1.9 LB 490 Tower-Sens Nomenclature ...........................2 – 136
2 Installation ...................................................................... 2 – 139
2.1 Transport to the Installation Site..............................2 – 141
2.2 Source-Detector Arrangements............................... 2 – 143
2.3 Detector Protection................................................. 2 – 145
2.4 Detector Installation ............................................... 2 – 147
2.5 Mounting the Shielding .......................................... 2 – 160
3 Electrical Installation........................................................ 2 – 183
3.1 Conduits ................................................................2 – 184
3.2 Terminals ................................................................2 – 187
3.3 Switch Setting ........................................................2 – 189
3.4 Connecting the Uni-Probe .....................................2 – 192
3.5 Uni-Probe with Ex i Current Output ........................ 2 – 195
3.6 Uni-Probe with Signal Output Profibus PA /
FOUNDATION
™
Fieldbus (not intrinsically safe)........2 – 206
3.7 Uni-Probe with Intrinsically Safe Signal Output
Profibus PA / FOUNDATION
™
Fieldbus.....................2 – 209
4 Repair, Maintenance and Service ..................................... 2 – 213
4.1 General Safety Precautions ..................................... 2 – 213
4.2 Visual Inspection of the Uni-Probe ..........................2 – 216
4.3 Checking the Connection Box ................................2 – 217
4.4 Trouble Shooting ....................................................2 – 218
4.5 Replacing the Complete Uni-Probe ........................ 2 – 220
4.6 Replacing the Electronics Module............................2 – 222
4.7 Replacing the Crystal-Multiplier Assembly
(for Point Detector)................................................. 2 – 225
4.8 Replacing the Multiplier (for Rod Detector) ............. 2 – 227
