BERTHOLD TECHNOLOGIES Uni-Probe LB 490 - Page 86

38477BA2B
1 – 86 25.5.09
10 Safety instructions ATEX/FM/CSA Volume 1
Ex temp. range
IIB
-40 … +80°C -20 … +50°C -20 … +60°C -40 … +80°C -20 … +60°C -40 … +80°C
Operat. temp.
range
-40 … +50°C -20 … +50°C -20 … +50°C -40 … +50°C -20 … +50°C -40 … +50°C
Approval according to FM / CSA
FM / CSA
Approval
Cl.I Div1&2
Gr.A,B,C,D
Cl.II Div1&2
Gr.E,F,G
––
Cl.I Div1&2
Gr.A,B,C,D
Cl.II Div1&2
Gr.E,F,G
–
Cl.I Div1&2
Gr.A,B,C,D
Cl.II Div1&2
Gr.E,F,G
Signal output
passive, can
be switched
to active
passive passive passive passive passive
Ex temp. range
-50 … +50°C – – -50 … +50°C – -50 … +50°C
Operat. temp.
range
-40 … +50°C – – -40 … +50°C – -40 … +50°C
Special device
Second current
output
no no no no no no
LB 490Type Uni-Probe ID no. 38477-XXX Super-Sens ID no. 53214-005 … 007 Tower-Sens ID no. 50250-005 … 007 Uni-Probe ID no. 47678-XXX Super-Sens ID no. 53214-009 … 016 Tower-Sens ID no. 50250-009 … 016 Uni-Probe ID no. 50040-XXX Super-Sens ID no. 53214-057 … 064 Tower-Sens ID no. 50250-057 … 064 Uni-Probe ID no. 50035-XXX Super-Sens ID no. 53214-049 … 056 Tower-Sens ID no. 50250-049 … 056 Uni-Probe ID no. 50041-XXX Super-Sens ID no. 53214-033 … 040 Tower-Sens ID no. 50250-033 … 040 Uni-Probe ID no. 50036-XXX Super-Sens ID no. 53214-025 … 032 Tower-Sens ID no. 50250-025 … 032
