Sync Camera Assembly
47
AMF 8230 /8270 Power/Reset Cable (Part No. 57-500210-000)
(1) TO J9-RIGHT LANE OR J10 (2) POWER “NO” (3) POWER “COM”
ON DISTRIBUTION BOARD
(4) CYCLE “NO” (5) CYCLE “COM” (6) TO AMF PINSETTER
AMF Sweep Switch Cable (Part No. 57-500211-000)
(1) TO DISTRIBUTION BOARD (2) NO CONNECTION (3) SWEEP
J1-LEFT LANE OR J2-RIGHT
LANE
(4) GROUND (5) NORMALLY CLOSED OF (6) COMMON OF SWEEP SWITCH
SWEEP
(7) TO PINSETTER SWEEP SWITCH
(10)
TO AMF 8290
(1)
TO J10
ON DISTRIBUTION
BOARD
(2)
TO J3
ON DISTRIBUTION
BOARD
(3)
TO J9
ON DISTRIBUTION
BOARD
1
2
4
3
RED
57-500212-000
BLACK
RED
BLACK
2
4
3
YELLOW
ORANGE
1
WHITE
GREEN
3
4
BLUE
2
1
BLACK
BROWN
RED
5
NC
3
4
2
1
6
8
7
5
BROWN
BLUE
ORANGE
YELLOW
GREEN
WHITE
RED
BLACK
(5) LEFT
(4) RIGHT
LEFT FOUL +
LEFT FOUL -
RIGHT FOUL -
RIGHT FOUL +
CYCLE "COM"
POWER "NO"
CYCLE "NO"
POWER "COM"
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
CYCLE "COM"
POWER "NO"
CYCLE "NO"
POWER "COM"
(6)
(7)
(8)
(9)
AMF 8290XL Foul/Reset Cable (Part No. 57-500212-000)
(1) TO J10 ON DISTRIBUTION (2) TO J3 ON DISTRIBUTION (3) TO J9 ON DISTRIBUTION BOARD
BOARD BOARD
(4) RIGHT (5) LEFT (6) POWER “NO”
(7) POWER “COM” (8) CYCLE “NO” (9) CYCLE “COM”
(10) TO AMF 8290
