NOTE

For details on the settings

See Help.

"How to Use Help"

About the sheets displayed by Windows

The following sheets are displayed by Windows. For more details, see Windows Help.

[General] sheet

[Sharing] sheet

[Ports] sheet

[Advanced] sheet

[Color Management] sheet

[Security] sheet

About the printer driver

The functions of the printer driver may be changed due to upgrade.

㻝㻣㻥㻌㻛㻌㻠㻡㻞
