07K5-06W

This section describes the procedure for specifying the settings using the Remote UI. To specify the settings using FTP

Client, see "FTP Client."

Start the Remote UI, and then log in as Administrator.

"Starting the Remote UI"

Select [Information] from the [Device Manager] menu.

Click [Change] under [Security].

Configure the SNMP v. 1 protocol.

Restricting the Users Who Can Monitor/Change the Settings Using the

SNMP Protocol

㻟㻠㻢㻌㻛㻌㻠㻡㻞
