07K5-023
By installing the optional paper feeder in addition to the supplied multi-purpose tray and paper drawer, the printer can feed
up to 800 sheets of paper continuously and automatically.
<If the printer is already installed>
When installing the paper feeder in the printer after installing the printer, move the printer to an appropriate location
temporarily.
"Moving the Printer"
For details on the precautions for when installing the paper feeder, see "Attention (Printer Installation)."
1
Take the paper feeder out of the box.
2
Remove the tape attached to the position shown in the figure.
3
Pull out the paper drawer of the paper feeder.
Installing the Paper Feeder
㻥㻡㻌㻛㻌㻠㻡㻞
To Next Page
