07K5-014
Part Name
Front View
(1) Output Tray (4) Duplex Print Transport Guide (7) Control Panel (10) Lift Handles
(2) Front Cover
(5) Paper Drawer (8) Ventilation Slots (11) Power Switch
(3) Multi-purpose Tray
(6) Auxiliary Tray (9) Open Button
Rear View
(1) Power Socket (6) Output Selection Cover (11) ERR Indicator (Orange)
(2) Duplex Unit Cover
(7) Rating Label (12) LNK Indicator (Green)
(3) Paper Size Switch Lever
(8) Lift Handles (13) 100 Indicator (Green)
(4) Ventilation Slots
(9) Sub-output Tray (14) LAN Connector
(5) Rear Cover
(10) Reset Button (15) USB Connector
Interior View
Names and Dimensions of Each Part
