Canon LBP6310dn - The Overall Surface of the Paper Is Printed in Black Completely

To Next Page

To Previous Page

07K5-094

Perform the following procedure.

<Cause> The drum in the toner cartridge is deteriorated.

Solution

Replace the toner cartridge with a new one.

"Toner Cartridge Replacement"

The Overall Surface of the Paper Is Printed in Black Completely

㻠㻟㻥㻌㻛㻌㻠㻡㻞
