NOTE

Using Preview to specify the setting

You can also specify a page layout by repeatedly left-clicking within the document image or right-clicking on Preview

when [

] is selected.

Specify the page order layout on paper.

Click [OK].

For details on the basic printing procedure, see "Basic Printing Procedure."
