Set the gutter.

(1) Click [Gutter].

(2) Specify each setting.

For more details on each setting, see Help.

"How to Use Help"

(3) Click [OK]. Then, the [Finishing] sheet reappears.

Click [OK].

For details on the basic printing procedure, see "Basic Printing Procedure."
