accordance with
ISO 9296)
*
Indicates the sound pressure level of each bystander position is below the ISO 7779
absolute criteria for the background noise level.
Operating
environment
(Printer unit only)
Operating environment
Temperature range: 10 to 30°C (50 to 86°F)
Humidity range: 20 to 80% RH (no condensation)
Host interface
USB interface
Hi-Speed USB/USB
Network interface
Shared 10BASE-T/100BASE-TX (RJ-45)
Full duplex/Half duplex
User interface
Five LED indicators
One operation key
Power supply 220 to 240 V (±10%), 50/60 Hz (±2 Hz)
Power consumption
(at 20°C (68°F))
Maximum: 1,170 W or less
Average during operation: Approx. 540 W
Average during standby: Approx. 9 W
Average during sleep mode (When LAN is connected): Approx. 1 W
Average during sleep mode (When USB is connected): Approx. 1.2 W
Even if the power of the printer is turned OFF, power is consumed only slightly while the
power plug is inserted into the AC power outlet.
To cut the power consumption completely, unplug the power plug from the AC power
outlet.
Consumables
Toner cartridge
Canon Cartridge 719
Canon Cartridge 719 H
For details on the yield, see "Replacement Timing" in "Consumables."
Weight
Printer unit and included parts
Printer unit (excluding the toner cartridge): Approx. 11.2 kg
Toner cartridge: Approx. 0.8 kg
Consumables and optional accessories
Toner cartridge (Canon Cartridge 719): Approx. 0.8 kg
Toner cartridge (Canon Cartridge 719 H): Approx. 1.0 kg
Paper Feeder Unit PF-44 (including the drawer): Approx. 4.1 kg
Software Specifications
Printing software Canon Advanced Printing Technology (CAPT) software
Printable area
Data can be printed with a margin of 5.0 mm.
(10 mm for envelopes)
For details, see "Printable Area."
Network interface
Supported protocol
TCP/IP
TCP/IP
Frame type: Ethernet II
Printing software
Windows Standard TCP/IP Port (Port 9100)
