SLM-5650B Satellite Modem
Revision 2
Front Panel Operation 5–30 MN-SLM-5650B
CONFIG: Remote  SerialConfig  Baudrate
Local M&C Bus Baud Rate:
38400 Baud (E)
Use the  arrow keys to select a Baud Rate of 2400, 4800, 9600, 19200, 38400
(default), 57600, or 115200, and then press [ENT].
CONFIG: Remote  Ethernet Config
Ethernet Config: IP Address/Range MAC
Gateway SNMP Option Card Addr (E)
Use the arrow keys to select IP Address/Range, MAC, Gateway, SNMP, or Option
Card Addr, and then press [ENT].
Option Function
IP
Address/Range
Select the IP Address.
MAC
Displays the modem’s MAC Address: This is programmed at the factory and is not
user changeable. If installed, the Gigabit Ethernet Interface’s MAC Address will also
be displayed.
Gateway
The IP Gateway Address is the default address that the modem will send all IP
responses when the message originated from a source outside the modems local
attached network.
SNMP
Select the Version, Communities or Traps. Detailed information follows.
Option Card
Addr
Select the NP Card Address Mode, Security, BPM, Traffic, IP, and Mgmt IP.
CONFIG: Remote  EthernetConfig  SNMP
SNMP: Version Communities Traps
(E)
Use the arrow keys to select Version, Communities, or Traps, and then press
[ENT].
CONFIG: Remote  EthernetConfig  SNMP  Version
SNMP Version: SNMP V1/V2c
(E)
Use the arrow keys to select SNMP V1/V2c or SNMP V3, and then press
[ENT].
