SLM-5650B Satellite Modem
Revision 2
Appendix B B–6 MN-SLM-5650B
Modulation Type Overhead
R-S Code
Word
R-S Depth Data Rate (kbps) Symbol Rate (ksps)
QPSK 3/4 IESS-308 Off N/A 8448 5632
QPSK 3/4 IESS-308 Off N/A 32064 21376
QPSK 3/4
IESS-308
Off
N/A
34368
22912
QPSK 3/4
IESS-308
Off
N/A
44736
29824
QPSK 3/4 IESS-308 194,178 4, 8, 16 1544 1217.858
QPSK 3/4 IESS-308 194,178 4, 8, 16 2048 1584.06
QPSK 3/4
IESS-308
194,178
4, 8, 16
6312
4682.247
QPSK 3/4
IESS-308
194,178
4, 8, 16
8448
6324.247
QPSK 3/4
IESS-308
194,178
4, 8, 16
32064
23393.438
QPSK 3/4 IESS-308 194,178 4, 8, 16 34368 25067.506
QPSK 3/4 IESS-308 219,201 4, 8, 16 1544 1217.512
QPSK 3/4
IESS-308
219,201
4, 8, 16
2048
1583.602
QPSK 3/4
IESS-308
219,201
4, 8, 16
6312
4680.836
QPSK 3/4 IESS-308 219,201 4, 8, 16 8448 6232.358
QPSK 3/4 IESS-308 219,201 4, 8, 16 32064 23386.269
QPSK 3/4
IESS-308
219,201
4, 8, 16
34368
25059.821
QPSK 3/4
IESS-308
225,205
4, 8, 16
1544
1225.756
QPSK 3/4 IESS-308 225,205 4, 8, 16 2048 1594.537
QPSK 3/4 IESS-308 225,205 4, 8, 16 6312 4714.537
QPSK 3/4 IESS-308 225,205 4, 8, 16 8448 6277.463
QPSK 3/4
IESS-308
225,205
4, 8, 16
32064
23557.463
QPSK 3/4
IESS-308
225,205
4, 8, 16
34368
25243.317
QPSK 3/4 IESS-308 126,112 4, 8, 1 1544 1254
QPSK 3/4 IESS-308 126,112 4, 8, 1 2048 1632
QPSK 3/4
IESS-308
126,112
4, 8, 1
6312
4830
QPSK 3/4
IESS-308
126,112
4, 8, 1
8448
6432
QPSK 3/4 IESS-308 126,112 4, 8, 1 32064 24144
QPSK 3/4 IESS-308 126,112 4, 8, 1 34368 25872
QPSK 3/4 IESS-308 208,192 4, 8, 16 1544 1216.472
QPSK 3/4
IESS-308
208,192
4, 8, 16
2048
1582.222
QPSK 3/4
IESS-308
208,192
4, 8, 16
6312
4676.583
QPSK 3/4 IESS-308 208,192 4, 8, 16 8448 626.667
QPSK 3/4 IESS-308 208,192 4, 8, 16 32064 23364.667
QPSK 3/4
IESS-308
208,192
4, 8, 16
34368
25036.667
QPSK 7/8
IESS-308
Off
N/A
1544
882.286
QPSK 7/8 IESS-308 Off N/A 2048 1170.286
QPSK 7/8 IESS-308 Off N/A 6312 3606.857
