Comtech EF Data SLM-5650B - Page 319

SLM-5650B Satellite Modem
Revision 2
Appendix B B–7 MN-SLM-5650B
Modulation Type Overhead
R-S Code
Word
R-S Depth Data Rate (kbps) Symbol Rate (ksps)
QPSK 7/8 IESS-308 Off N/A 8448 4827.428
QPSK 7/8 IESS-308 Off N/A 32064 20040.571
QPSK 7/8
IESS-308
Off
N/A
34368
21473.714
QPSK 7/8
IESS-308
Off
N/A
44736
27922.857
QPSK 7/8 IESS-308 194,178 4, 8, 16 1544 1057.592
QPSK 7/8 IESS-308 194,178 4, 8, 16 2048 1371.48
QPSK 7/8
IESS-308
194,178
4, 8, 16
6312
4027.069
QPSK 7/8
IESS-308
194,178
4, 8, 16
8448
5357.355
QPSK 7/8
IESS-308
194,178
4, 8, 16
32064
20065.233
QPSK 7/8 IESS-308 194,178 4, 8, 16 34368 21500.148
QPSK 7/8 IESS-308 194,178 4, 8, 16 44736 27957.265
QPSK 7/8
IESS-308
219,201
4, 8, 16
1544
1057.296
QPSK 7/8
IESS-308
219,201
4, 8, 16
2048
1371.087
QPSK 7/8 IESS-308 219,201 4, 8, 16 6312 4025.859
QPSK 7/8 IESS-308 219,201 4, 8, 16 8448 5355.736
QPSK 7/8
IESS-308
219,201
4, 8, 16
32064
20059.087
QPSK 7/8
IESS-308
219,201
4, 8, 16
34368
21493.561
QPSK 7/8 IESS-308 219,201 4, 8, 16 44736 27948.691
QPSK 7/8 IESS-308 225,205 4, 8, 16 1544 1064.362
QPSK 7/8 IESS-308 225,205 4, 8, 16 2048 1380.46
QPSK 7/8
IESS-308
225,205
4, 8, 16
6312
4054.743
QPSK 7/8
IESS-308
225,205
4, 8, 16
8448
5394.397
QPSK 7/8 IESS-308 225,205 4, 8, 16 32064 20205.826
QPSK 7/8 IESS-308 225,205 4, 8, 16 34368 26150.843
QPSK 7/8
IESS-308
225,205
4, 8, 16
44736
28153.422
QPSK 7/8
IESS-308
126,112
4, 8, 16
1544
1088.571
QPSK 7/8 IESS-308 126,112 4, 8, 16 2048 1412.571
QPSK 7/8 IESS-308 126,112 4, 8, 16 6312 4153.714
QPSK 7/8 IESS-308 126,112 4, 8, 16 8448 5526.857
QPSK 7/8
IESS-308
126,112
4, 8, 16
32064
20708.571
QPSK 7/8
IESS-308
126,112
4, 8, 16
34368
22189.714
QPSK 7/8 IESS-308 126,112 4, 8, 16 44736 28854.857
QPSK 7/8 IESS-308 208,192 4, 8, 16 1544 1056.405
QPSK 7/8
IESS-308
208,192
4, 8, 16
2048
1369.905
QPSK 7/8
IESS-308
208,192
4, 8, 16
6312
4022.214
QPSK 7/8 IESS-308 208,192 4, 8, 16 8448 5350.857
QPSK 7/8 IESS-308 208,192 4, 8, 16 32064 20040.571
