SLM-5650B Satellite Modem
Revision 2
Appendix C C–37 MN-SLM-5650B
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to
Query
CnC Power Ratio
Monitor
N/A 6 bytes Query only.
When CnC is enabled and locked, the ratio between the interferer
and the desired signal power is readable in dB. The precision is
0.1 dB.
Example 1: CRM = +02.8 (interferer > desired)(format=sdd.d)
Example 2: CRM = LT10.0 (less than -10.0 dB)
Example 3: CRM = GT10.0 (greater than +10.0 dB)
Example 4: CRM = 9999.9 (not locked or CnC not enabled)
N/A CPR? CPR=xxxxxx
(see Description
of Arguments)
Carrier-in-Carrier
(CnC)
Re-Acquisition
Time
CRA= 3 bytes Command or Query.
CnC re-Acquisition time in seconds, from 10 to 999. This is the
time wherein CnC will start searching for the delay and frequency
offset if a long duration of unlock occurs.
Example: CRA = 010
CRA=
CRA?
CRA*
CRA#
CRA? CRA=xxx
(see Description
of Arguments)
Carrier-in-Carrier
(CnC) Ratio
Monitor
N/A
4 bytes
Query only.
When CnC is enabled and locked, the ratio between the interferer
and the desired signal power is readable in dB.
Example 1: CRM = +02 (interferer > desired)
Example 2: CRM = LT10 (less than -10 dB)
Example 3: CRM = GT10 (greater than +10 dB)
Example 4: CRM = 99.9 (not locked or CnC not enabled)
N/A
CRM?
CRM=xxxx
(see Description
of Arguments)
Carrier-in-Carrier
(CnC) Min/Max
Search Delay
CSD- 6 bytes Command or Query.
CnC min/max delay value in milliseconds, from 0 to 300 ms in the
form xxxyyy, where:
xxx = min delay
yyy = max delay
Example: CSD = 010300
CSD=
CSD?
CSD*
CSD#
CSD? CSD=xxxyyy
(see Description
of Arguments)
