SLM-5650B Satellite Modem
Revision 2
Appendix C C–42 MN-SLM-5650B
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to
Query
Live Unit Faults N/A 8 bytes Query only.
Live Unit Faults are returned as a 32 bit Hexadecimal value. Bit
values are defined as follows:
80000000 = Power Supply out of range
40000000 = Reference not locked
20000000 = 250 MHz Clock not locked
10000000 = Ext Reference Activity
08000000 = CPLD #1 not loaded
04000000 = CPLD #2 not loaded
02000000 = Mod FPGA not loaded
01000000 = Demod FPGA not loaded
00800000 = Option Card FPGA not loaded
00400000 = TRANSEC card not ready
00200000 = Modem over temperature
00100000 = Cooling Fan
00080000 = NP Card Mailbox Comm Error
00040000 = TRANSEC Card Mailbox Comm Error
Example: LUF = 00000000 indicates No Unit Faults
N/A LUF?
LUF=xxxxxxxx
(see Description
of Arguments)
Modem
Reference Clock
MRC= 1 byte Command or Query.
Modem Reference Clock (for Frequency Accuracy), where:
0 = Internal
1 = External 1 MHz
2 = External 5 MHz
3 = External 10 MHz
Example: MRC = 0 (Internal)
MRC=
MRC?
MRC*
MRC#
MRC?
MRC=x
(see Description
of Arguments)
