Control Techniques unidrive sp User Manual

Menu 6
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
128 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
The run time clock increments when the drive inverter is active to indicate the number of minutes that the drive has been running since leaving the
Control Techniques factory. This clock may be used for time stamping the trip log if Pr 6.28 = 1.
Pr 6.24 and Pr 6.25 form the energy meter that indicates energy supplied to/from the drive in kWh. For motor control modes a positive value indicates
net transfer of energy from the drive to the motor. For Regen mode a positive value indicates a net transfer of energy from the supply to the drive. The
energy meter is reset and held at zero when Pr 6.17 is one.
Instantaneous read out of the cost/hour of running the drive. This requires Pr 6.16 to be set up correctly.
See Pr 6.18 on page 127.
6.23 Run time: hours.minutes
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
21 1 1 11
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 23.59 Hours.Minutes
Update rate Background write
6.24 Energy meter: MWh
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
11 1 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
±999.9 MWh
Update rate Background write
6.25 Energy meter: kWh
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
21 1 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
±99.99 kWh
Update rate Background write
6.26 Running cost
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
±32,000
Update rate Background write
6.27 Time before filter change due
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
111 11
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 30,000 hrs
Update rate Background read
