Control Techniques unidrive sp User Manual

Menu 10
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
166 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
Enc16 Drive encoder trip: EnDat encoder - The number of comms bits per period for a linear encoder exceeds 255.
166
Select a different type of encoder.
Faulty encoder.
Enc17
Drive encoder trip: The periods per revolution obtained during auto-configuration for a rotary SINCOS encoder is not a
power of two.
167
Select a different type of encoder.
Faulty encoder.
ENP.Er Data error from electronic nameplate stored in selected position feedback device
176 Replace feedback device
Et External trip from input on terminal 31
6
Check terminal 31 signal
Check value of Pr 10.32
Enter 12001 in Pr xx.00 and check for parameter controlling Pr 10.32
Ensure Pr 10.32 or Pr 10.38 (=6) are not being controlled by serial comms
HF01 Data processing error: CPU address error
Hardware fault - return drive to supplier
HF02 Data processing error: DMAC address error
Hardware fault - return drive to supplier
HF03 Data processing error: Illegal instruction
Hardware fault - return drive to supplier
HF04 Data processing error: Illegal slot instruction
Hardware fault - return drive to supplier
HF05 Data processing error: Undefined exception
Hardware fault - return drive to supplier
HF06 Data processing error: Reserved exception
Hardware fault - return drive to supplier
HF07 Data processing error: Watchdog failure
Hardware fault - return drive to supplier
HF08 Data processing error: Level 4 crash
Hardware fault - return drive to supplier
HF09 Data processing error: Heap overflow
Hardware fault - return drive to supplier
HF10 Data processing error: Router error
Hardware fault - return drive to supplier
HF11 Data processing error: Access to EEPROM failed
Hardware fault - return drive to supplier
HF20 Power stage recognition: serial code error
220 Hardware fault - return drive to supplier
HF21 Power stage recognition: unrecognised frame size
221 Hardware fault - return drive to supplier
HF22 Power stage recognition: multi module frame size mismatch
222 Hardware fault - return drive to supplier
HF23 Power stage recognition: multi module voltage rating mismatch
223 Hardware fault - return drive to supplier
HF24 Power stage recognition: unrecognised drive size
224 Hardware fault - return drive to supplier
HF25 Current feedback offset error
225 Hardware fault - return drive to supplier
Trip Diagnosis
