Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menu 3
Regen
Unidrive SP Advanced User Guide 79
Issue Number: 7 www.controltechniques.com
When regen mode is selected Pr 3.08 is the destination for the digital input on terminal 25 (T25) as default. This input, or an alternative input, should
be connected to an auxiliary contact on the soft-start contactor so that it follows the state of the contactor. The regen unit will only attempt to
synchronise to the supply when this parameter is one. This parameter is also used to monitor the contactor when the regen unit running. If at any time
this parameter is zero the regen unit is immediately disabled.
When the unit has been enabled and successfully synchronised this bit will become active. If the regen unit attempts to re-synchronise or trips, this bit
becomes inactive. When regen mode is selected this bit is routed to a the digital output on terminal 24 (T24) as default. The output, or an alternative
output, should be used to enable the motor drive(s) connected to the DC bus of the regen unit.
Power feed-forward compensation can be used to reduce the transient DC bus voltage produced when a fast load transient occurs on drives
connected to the Regen unit. 100.0% power feed-forward is equivalent to an active current of Rated drive current / 0.45 (i.e. over current trip level)
and an AC terminal peak phase voltage equal to DC_VOLTAGE_MAX / 2. This scaling is the same as the power output from Pr 5.03 when high speed
output mode is used (see section 5.8 Menu 7: Analog I/O ). Therefore an analog output of the drive supplying the load and analog input 2 or 3 of the
drive acting as the supply Regen unit can be connected together to give power feed-forward compensation without further scaling if the two drives are
of equal rating. If the ratings are different the analog input scaling must be used to give the correct power feed-forwards, where the scaling is given by:
Load drive Rated drive current / Regen unit rated drive current
3.08
Soft-start contactor closed
Drive modes Regen
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate 4ms read
3.09
Enable motor drive
Drive modes Regen
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Update rate 4ms write
3.10
Power feed-forward compensation
Drive modes Regen
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
12 1 1
Range Regen ±100 %
Default Regen 0.00
Update rate 4ms read
