Control Techniques unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menu 7
Unidrive SP Advanced User Guide 141
Issue Number: 7 www.controltechniques.com
The following modes are available for the analog outputs.
If high speed update mode is selected and the source for the output is one of the parameters designated for high speed analog output operation (see
start of this section) the output is updated at a higher rate with special scaling. If the parameter selected is not designated for this mode the output is
updated at the normal rate. If speed feedback or power is selected for high speed mode for both analog output 1 and analog output 2 the setting is
ignored for analog output 2. If the high speed mode is selected the output is always a voltage signal.
7.19 T9 analog output 1 source
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop
Closed-loop vector, Servo
Regen
Pr 5.01
Pr 3.02
Pr 4.01
Update rate Background read
7.20 T9 analog output 1 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.000 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
7.21 T9 analog output 1 mode
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 3
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
Parameter value Parameter string Mode
0 VOLt Voltage mode
1 0-20 0 - 20mA
2 4-20 4 - 20mA
3 H.Spd High speed up date mode
7.22 T10 analog output 2 source
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo
Regen
Pr 4.02
Pr 5.05
Update rate Read on drive reset
