Control Techniques unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menu 8
Unidrive SP Advanced User Guide 151
Issue Number: 7 www.controltechniques.com
When this parameter is 0, Pr 8.25 and Pr 8.26 are set up automatically according to the setting of the reference select Pr 1.14. Setting this parameter
to 1 disables this function.
8.39 T28 & T29 digital input auto-selection disable
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Open-loop, Closed-loop vector, Servo OFF (0)
Update rate Background read
Reference select Pr 1.14 Pr 8.25 set to: Pr 8.26 set to:
0, A1.A2 Reference selection by terminal input Pr 1.41 - Analog ref 2 select Pr 6.31 - jog
1, A1.Pr Analog reference 1 or presets selected by terminal input Pr 1.45 - preset select bit 0 Pr 1.46 - preset select bit 1
2, A2.Pr Analog reference 2 or presets selected by terminal input Pr 1.45 - preset select bit 0 Pr 1.46 - preset select bit 1
3, Pr Preset reference selected by terminal input Pr 1.45 - preset select bit 0 Pr 1.46 - preset select bit 1
4, Pad Keypad reference selected Pr 1.41 - Analog ref 2 select Pr 6.31 - jog
5, Prc Precision reference selected Pr 1.41 - Analog ref 2 select Pr 6.31 - jog
