Control Techniques unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menu 7
Unidrive SP Advanced User Guide 137
Issue Number: 7 www.controltechniques.com
When analog input 3 is in thermistor mode the display indicates the resistance of the thermistor as a percentage of 10KΩ
These parameters display the temperature of various parts of the drive in degrees Celsius. The power stage is monitored at two points (Pr 7.04 and
Pr 7.05) and the control board is also monitored (Pr 7.06). The following trips and alarms can are produced from the values in these parameters.
The threshold levels for the stack temperature trips and alarm vary between drive sizes.
The values displayed in the parameter are normally between -20 and +127°C. If the value measured from the thermistor exceeds the range from -20
to +150°C it is assumed that the device is either open-circuit or short-circuit.
7.01 T5/6 analog input 1 level
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
±100.00 %
Update rate 4ms write
7.02 T7 analog input 2 level
7.03 T8 analog input 3 level
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
±100.0 %
Update rate 4ms write
7.04 Stack temperature 1
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range
Open-loop, Closed-loop vector, Servo,
Regen
-128 to 127
o
C
Update rate Background write
7.05 Stack temperature 2
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range
Open-loop, Closed-loop vector, Servo,
Regen
-128 to 127
o
C
Update rate Background write
7.06 Control board temperature
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
-128 to 127
o
C
Update rate Background write
Parameter Trip Alarm
Pr 7.04
Stack temperature 1 (IGBT)
“O.ht2” if Pr 7.04 > Trip threshold
(Can be reset if Pr 7.04 < Trip threshold – 5°C)
“hot” if Pr 7.04 > Alarm threshold
Pr 7.05
Stack temperature 2 (power PCB)
“O.ht2” if Pr 7.05 > Trip threshold
(Can be reset if Pr 7.05 < Trip threshold – 5°C)
“hot” if Pr 7.05 > Alarm threshold
Pr 7.06
Control board temperature
“O.Ctl” if Pr 7.06 > 90°C
(Can be reset if Pr 7.04 < 85°C)
“hot” if Pr 7.06 > 85°C
