5.6 Menu 5: Motor control
Open loop
Figure 5-10 Menu 5 Open-loop logic diagram
2.01
Post ramp
reference
+
+
3.01
Slave frequency
demand
5.10
5.11
Motor rated
power factor
Motor number
of poles
5.02
Motor
voltage
5.03
Tot a l m o to r
power (kW)
√ 3 x V x I
Volt
L1 L2 L3
5.05
DC Bus
voltage
5.09
Motor rated
voltage
5.07
5.08
Motor rated
current
Motor rated
full load RPM
5.06
Motor rated
frequency
5.23
Voltage offset
5.17
Stator
resistance
5.15
Voltage boost
5.13
Dynamic V/f
select
Transient
inductance
4.02
4.20
4.17
4.01
Motor
current
magnitude
Motor magnetising
current
Motor active
current
Percentage
active current
Motormap
5.12
Autotune
5.24
5.14
Voltage
mode
5.01
Motor
frequency
5.04
Estimated
motor speed
Slip
compensation
0.XX
0.XX
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
Slip
compensation
enable
5.27
The parameters are all shown at their default settings
3.13
Frequency
slaving
enable
5.18
5.19
PWM
switching
frequency
High stability
space vector
modulation
Hertz
5.20
5.35
Quasi square
wave enable
Disable auto
switching
frequency
change
5.31
Voltage
controller
gain
http://nicontrols.com
