Control Techniques unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menu 21
Unidrive SP Advanced User Guide 317
Issue Number: 7 www.controltechniques.com
5.20 Menu 21: Second motor parameters
The following parameters are used instead of the normal motor set-up parameters when Pr 11.45 = 1.
When the alternative parameter set is being used by the drive the decimal point after the right hand digit in the 1st row is on.
Unlike the motor 1 (Pr 1.14) this parameter is not used for T28 and T29 digital input auto-selection (see Pr 8.39 on page 151).
Pr 21.03 defines how the value of Pr 1.49 is derived as follows:
*The bit Pr 1.41 to Pr 1.44 can be controlled to force the value of Pr 1.49:
all bits equal to zero gives 1,
Pr 1.41 = 1 then Pr 1.49 = 2
Pr 1.42 = 1 then Pr 1.49 = 3
Pr 1.43 = 1 then Pr 1.49 = 4
Pr 1.44 = 1 then Pr 1.49 = 5
21.01 Maximum reference clamp
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Closed-loop vector, Servo = VM
Range
Open-loop
Closed-loop vector, Servo
0 to 3,000.0Hz
SPEED_LIMIT_MAX rpm
Default
Open-loop
Closed-loop vector
Servo
EUR: 50.0, USA: 60.0
EUR: 1,500.0, USA: 1,800.0
3,000.0
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 1.06
Update rate Background read
21.02 Minimum reference clamp
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Closed-loop vector and Servo = VM
Range
Open-loop
Closed-loop vector and Servo
±3,000.0 Hz
±SPEED_LIMIT_MAX rpm
Default Open-loop, Closed-loop vector, Servo 0.0
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 1.07
Update rate Background read
21.03 Reference selector
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range Open-loop, Closed-loop vector, Servo 0 to 5
Default Open-loop, Closed-loop vector, Servo 0 (A1.A2)
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 1.14
Update rate 4ms read
Value of Pr 21.03 Display String Pr 1.49
0 A1.A2 *Selected by terminal input
1A1.Pr1
2A2.Pr2
3Pr3
4Pad4
5Prc5
