the enable to behave as an Et trip input. When the input becomes inactive an Et trip is initiated. This does not affect Pr 10.32 (Et trip parameter),
therefore an Et trip can be initiated in this mode either by making the enable inactive or setting Pr 10.32 to one.
This word is used to determine the status of the digital I/O by reading one parameter. The bits in this word reflect the state of Pr 8.01 to Pr 8.09.
8.11 T24 digital I/O 1 invert
8.12 T25 digital I/O 2 invert
8.13 T26 digital I/O 3 invert
8.14 T27 digital input 4 invert
8.15 T28 digital input 5 invert
8.16 T29 digital input 6 invert
8.17 Relay source invert
8.18 T22 24V output source invert
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default
Open-loop, Closed-loop vector, Servo
Regen
Pr 8.11 to Pr 8.17 = OFF (0), Pr 8.18 = On (1)
Update rate 4ms read
8.20 Digital I/O read word
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 511
Update rate Background write
Bit Digital I/O
0 T24 input / output 1
1 T25 input / output 2
2 T26 input / output 3
3 T27 input 4
4 T28 input 5
5 T29 input 6
6 Relay
7 T22 24V output
8 Enable
8.21 T24 digital I/O 1 source/destination
8.22 T25 digital I/O 2 source/destination
8.23 T26 digital I/O 3 source/destination
8.24 T27 digital input 4 destination
8.25 T28 digital input 5 destination
8.26 T29 digital input 6 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Default
Open-loop, Closed-loop vector, Servo
Regen
See Table 5-4 on page 148
See Table 5-5 on page 148
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Update rate Read on drive reset
