172 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
202,207,212
Fieldbus module category
Check value in Pr 15/16/17.50. The following table lists the possible error codes for the Fieldbus modules.
SLX.HF Solutions Module slot X trip: Solutions Module X hardware fault
200,205,210
Ensure Solutions Module is fitted correctly
Return Solutions Module to supplier
SLX.nF Solutions Module slot X trip: Solutions Module has been removed
203,208,213
Ensure Solutions Module is fitted correctly
Re-fit Solutions Module
Save parameters and reset drive
SL.rtd Solutions Module trip: Drive mode has changed and Solutions Module parameter routing is now incorrect
215
Press reset.
If the trip persists, contact the supplier of the drive.
SLX.tO Solutions Module slot X trip: Solutions Module watchdog timeout
203,208,211
Press reset.
If the trip persists, contact the supplier of the drive.
t010
User trip defined in 2
nd
processor Solutions Module code
10 SM-Applications program must be interrogated to find the cause of this trip
t036 to t038
User trip defined in 2
nd
processor Solutions Module code
36 to 38 SM-Applications program must be interrogated to find the cause of this trip
t040 to t089
User trip defined in 2
nd
processor Solutions Module code
40 to 89 SM-Applications program must be interrogated to find the cause of this trip
t099
User trip defined in 2
nd
processor Solutions Module code
99 SM-Applications program must be interrogated to find the cause of this trip
t111 to t160
User trip defined in 2
nd
processor Solutions Module code
111 to 160 SM-Applications program must be interrogated to find the cause of this trip
t168 to t175
User trip defined in 2
nd
processor Solutions Module code
168 to 175 SM-Applications program must be interrogated to find the cause of this trip
t177 to t178
User trip defined in 2
nd
processor Solutions Module code
177 to 178 SM-Applications program must be interrogated to find the cause of this trip
t216 to t217
User trip defined in 2
nd
processor Solutions Module code
216 to 217 SM-Applications program must be interrogated to find the cause of this trip
Trip Diagnosis
Error code Fieldbus Option Reason for fault
52 All except DPLCAN Control word user trip
61 All Invalid configuration parameters.
65 All except DPLCAN Network loss
66
DeviceNet, CANopen and
DPLCAN
"Bus-Off” Node sees an excessive number of transmission errors.
67 CANopen Node has not received a SYNC telegram within a specified time - to be defined.
68 CANopen Node has not received the guarding telegram within the time period specified.
69 DPLCAN
Node sends a data frame and no other node acknowledges
receipt of the frame message.
70 All
No valid Fieldbus Menu data available in the module to download to the drive –
The user may not have saved any data, or the data save may not have been
completed successfully.
71 DeviceNet
The External power supply has been lost. This trip will only occur if the module
was on line with a master when the loss occurs. i.e. will not occur if the power
supply is not present during module initialisation.
74 All The Solutions Module has overheated.
98 All The Solutions Module background task has not been completed.
99 All Software Fault.
